The basic idea behind using reverse polarity connectors is to prevent a user from trying to connect the wrong type of connector i.e a male connector to a male connector or female connector to a female connector as this can damage the connector and result in signal degradation at the connector interface.Ĭlick here to view reverse polarity connectors from the leading manufacturers on everything RF. In Reverse Polarity Male and Female connectors the 'center pin' of the Male connector is swapped with the 'receptacle' of the Female connector i.e., a reverse polarity male connector has a receptacle at the interface instead of a center pin and reverse polarity female connector has a center pin at the interface. Reverse Sma Connector (1307 products available) Crimp 3D-FB RG58U LMR195 RG142 RG400 Reverse RP SMA Male Jack Connector. Antenna connector is 'Reverse SMA' Supplied Accessories: Rapid Charger SBH-22 AC Adapter SAD-20B - 120 VAC Belt Clip SHB-18 Antenna Manufacturers Website.
The threaded portion is outside the connector. Alibaba Electrical Equipment & Supplies Connectors & Terminals Connectors Wholesale reverse sma connector. On the other hand, a traditional female connector (Standard Polarity) consists of an outer body, a ferrule and a receptacle instead of a center pin. The RP-SMA connector (1) (also called Reverse SMA) has a metal tube as inner conductor, the RP-SMA socket (2) has the pin as inner conductor (see figure on. The threaded portion is inside the connector.
As depicted in the figure above, a traditional Male connector (Standard Polarity) consists of an outer body, a ferrule and a center pin.
